| Technical Data |
 |
Application |
|
| Product |
|
Short description |
|
Temp.-range |
|
Properties |
|
|
|
| BERULIT 443 |
|
Priming lubricant for large open gear drives operating under heavy loads and low circumferential speeds to be applied by hand. Priming lubricant for gear drives before starting the running-in process. For small rotating assemblies it can also be used as service lubricant. Also suitable for the lubrication of slide ways and guide pads. |
|
-20°C to +180 °C |
|
Good adhesion, high lubricant film pressure resistance, excellent wear protection, no hardening or brittling of lubricant film, does not contain any bituminous ingredients, solvents or toxic heavy metals. |
|
Open gear drives of small mixing drums, dryers and mills without automatic lubrication system Slew ring gears of converters, cranes, crushers and excavators with a central lubrication system or for manual application. Guide pads of crane booms. |
| BERULIT EL 420 |
|
Running-in lubricant for large open gear drives operating under heavy loads and high circumferential speeds to be applied by automatic spray systems. |
|
-20°C to +180 °C |
|
Good adhesion, high lubricant film pressure resistance, excellent wear protection, no hardening or brittling of lubricant film, does not contain any bituminous ingredients, solvents or toxic heavy metals. |
|
Open gear drives of mixing drums, dryers, ball mills, rotary kilns. Slew ring gears of converters, cranes, crushers and excavators with spray or central lubrication systems. |
| BERULIT GA 2500 |
|
Service lubricant for large open gear drives operating under heavy loads and high circumferential speeds to be applied by automatic spray systems. |
|
+5°C to +200 °C |
|
Thermal stability -30°C to 250°C, good adhesion, high lubricant film pressure resistance, excellent wear protection, no hardening or brittling of lubricant film, does not contain any bituminous ingredients, solvents or toxic heavy metals. Contains graphite. Base oil viscosity: ca. 2500. |
|
Open gear drives of mixing drums, dryers, ball mills, rotary kilns. Slew ring gears of converters, drag lines, cranes, crushers and excavators with spray or central lubrication systems. Heavily loaded tooth couplings. |
| BERULIT GA 2500 FLUID |
|
Service lubricant for large open gear drives operating under heavy loads and high circumferential speeds to be applied by immersion or circulation systems. |
|
+0 °C to +200 °C |
|
Thermal stability -30°C to 250°C, very good adhersion, high lubricant film pressure resistance, excellent wear protection, no hardening or brittling of lubricant film, does not contain any bituminous ingredients, solvents or toxic heavy metals. Contains graphite. Base oil viscosity: ca. 2500. |
|
Open gear drives of mixing drums, dryers, ball mills, rotary kilns. Heavily loaded tooth couplings. |
| BERULIT GA 400 |
|
Service lubricant for large open gear drives operating under heavy loads and high circumferential speeds to be applied by automatic spray systems. |
|
-20°C to +180 °C |
|
Good adhesion, high lubricant film pressure resistance, excellent wear protection, no hardening or brittling of lubricant film, does not contain any bituminous ingredients, solvents or toxic heavy metals. Contains graphite. Base oil viscosity: ca. 500. |
|
Open gear drives of mixing drums, dryers, ball mills, rotary kilns. Slew ring gears of converters, cranes, crushers and excavators with spray or central lubrication systems. |
| BERULIT GA 800 |
|
Service lubricant for large open gear drives operating under heavy loads and high circumferential speeds to be applied by automatic spray systems. |
|
-10°C to +180 °C |
|
Good adhesion, high lubricant film pressure resistance, excellent wear protection, no hardening or brittling of lubricant film, does not contain any bituminous ingredients, solvents or toxic heavy metals. Contains graphite. Base oil viscosity: ca. 1000. |
|
Open gear drives of mixing drums, dryers, ball mills, rotary kilns. Slew ring gears of converters, cranes, crushers and excavators with spray or central lubrication systems. |
| BERULIT GA 800 FLUID |
|
Service lubricant for large open gear drives operating under heavy loads and high circumferential speeds to be applied by automatic spray systems. |
|
-10°C to +180 °C |
|
Thermal stability -30°C to 250°C, good adhesion, high lubricant film pressure resistance, excellent wear protection, no hardening or brittling of lubricant film, does not contain any bituminous ingredients, solvents or toxic heavy metals. Contains graphite. Base oil viscosity: ca. 1000. |
|
Open gear drives of mixing drums, dryers, ball mills, rotary kilns. Slew ring gears of converters, cranes, crushers and excavators with spray or central lubrication systems. |
|
The above data correspond to latest technology, modifications reserved. This information is intended as a guide and does not necessarily represent a marketing specification. In individual cases tests have to be carried out by the consumer. Further data upon request.
|
